U wall cabinet – FINEN WZ Series WZ6406 welded structure wall mount enclosure with tempered glass door,

High Quality Welded Structure 9U Wall Cabinet

Categories: , Brand:

High Quality Welded Structure 9U Wall Cabinet – FINEN WZ Series WZ6406 | Zoomtech

A 9U wall cabinet provides a professional-quality network installation at a value price. Zoomtech supplies the FINEN 9U wall cabinet (Model: WZ Series WZ6406) — a welded structure wall mount enclosure with improved load bearing capacity and stability, designed to fit EIA-compliant 19″ rack mountable equipment properly and securely. This 9U wall cabinet can be wall-mounted or self-standing and features removable, locking side panels for easy access.

Product Overview

The 9U wall cabinet (Model: WZ Series WZ6406), available through Zoomtech, is manufactured by FINEN from high-quality cold rolled steel. This 9U wall cabinet features a 5mm tempered glass front door, removable side panels, an L-shaped spring pin for fast door opening direction changes, and optional fans to keep equipment cool — perfect for network wiring closets, retail locations, classrooms, and back offices with limited floor space.

Available from Zoomtech — manufactured by FINEN.

Standards & Compliance

This 9U wall cabinet complies with the following international standards:

  • ANSI/EIA RS-310-D

  • DIN41497 Part 1

  • IEC297-2

  • DIN41494 Part 7

  • GBIT3047.2-92

Front Door: Tempered Glass Door

Quick Details

Specification Details
Supplier Zoomtech
Manufacturer FINEN
Model Number WZ Series WZ6406
Material High Quality Cold Rolled Steel
Degree of Protection IP20
Type Weld Structure Network Cabinet
Capacity 4U / 6U / 9U / 12U / 15U / 18U
Color Black, Gray, White
Installation 19″ Installation
Depth 450mm / 600mm
Width 600mm
Front Door 5mm Thickness Tempered Glass Door
Side Panels Removable
Thickness Mounting Profile 2.0mm; Mounting Angle 1.2mm
Cable Access Top Open Brackets for Cable and Wire Access
Loading Capacity 60kgs (Static)
Optional Accessories Fans, Shelf, PDU, Cable Manager, and Others
Packing Firm Carton / Assembly Packing Only
Package Include 1 x Network Cabinet, 1 Set of Keys, Some Screws
Shipping Sea, Air, Train, Truck
Application Server Room
HS Code 8473309000

Product Size Chart

Model No. Capacity (U) Width (mm) Depth (mm) Height (mm) Packing Dimension (mm) Volume (CBM)
WM.6404 4 600 450 280 635×485×160 0.049
WM.6604 4 600 600 280 635×635×230 0.093
WM.6406 6 600 450 368 635×485×160 0.049
WM.6606 6 600 600 368 635×635×230 0.093
WM.6409 9 600 450 501 635×485×235 0.072
WM.6609 9 600 600 501 635×635×231 0.093
WM.6412 12 600 450 635 665×595×236 0.093
WM.6612 12 600 600 635 665×635×231 0.098
WM.6415 15 600 450 769 635×940×98, 802×460×132 0.137
WM.6615 15 600 600 769 635×757×236 0.113
WM.6418 18 600 450 901 635×940×98, 935×460×132 0.137
WM.6618 18 600 600 901 935×630×236 0.139

Features

  • Exquisite design with precise dimensions and craftsmanship

  • Easy installation

  • Mounts to wall or rolls on floor with optional caster kit

  • Saves valuable workspace

  • Top cover is available for fans

  • Optional locks for side panels

  • Zinc plated mounting profile

  • Meets IP20 protection grade

  • Secure, firm and reliable

  • Houses EIA-standard 19 in. rack equipment

  • Excellent air ventilation design with AC 120mm cooling fans

  • Three ways, top, bottom, and rear cabling tunnels

  • Easy to install and maintain

  • Certification: ISO 9001:2000

  • OEM service available

  • Fans and PDU are optional

  • Perfect for network wiring closets, retail locations, classrooms, back offices, and other areas with limited floor space where equipment needs to be secure, organized, and out of the way

Key Advantages

  1. Welded Structure – Improves load bearing capacity and stability.

  2. 5mm Tempered Glass Front Door – Strong and easy to monitor equipment.

  3. Removable, Locking Side Panels – Convenient access and added security.

  4. L-Shaped Spring Pin – Fast door opening direction changes.

  5. Wall-Mount or Self-Standing – Flexible installation to suit your space.

  6. Optional Cooling Fans – Keep your equipment running cool.

Why Buy from Zoomtech?

  • Authorized supplier of FINEN network cabinets and wall mount enclosures.

  • Expert product guidance — we help you match the right cabinet to your equipment and space.

  • Competitive pricing on single units and bulk orders.

  • Fast response on quotes, lead times, and shipping.

  • After-sales support for configuration, accessories, and replacements.

About the Manufacturer – FINEN

FINEN is a manufacturer with 24 years’ experience, covering an area of 50,000 square meters, with more than 500 employees and a professional R&D team. Their advanced equipment — imported from Japan and Germany — includes AMADA CNC Punch Machines, TRUMPF Laser Cutting Machines, AMADA CNC Bending Machines, and CNC Automatic Spraying Lines, with a production capacity of 12,000 sets per month.

What FINEN produces:

  1. Wall Mounted Rack – Glass front door (removable), side panel with handy latches or locks, flat packing available.

  2. Floor Standing Rack – Model AS (glass front door, mesh rear door), Model A3 (mesh front and rear door), Model H1 (hexagonal mesh doors, welded with section bar frame), Model H2 (nine-folded frame), Model H3 (arc hexagonal mesh doors, welded with section bar frame, two section side panel).

  3. OEM Service and Customized Products

Applications

  • Network wiring closets

  • Retail locations

  • Classrooms

  • Back offices

  • Server rooms

  • Other areas with limited floor space

Rack cabinets for information technology and telecommunication appliances:

  • Various 19-inch servers

  • Digital Video Recorders (DVR), KVM, and routers

  • Patch panels, switches, and CCTV system equipment

  • Telephone systems and communication equipment

  • Network cabling and data center systems

  • UPS and weak current equipment

  • Other rack mount equipment

Useful Resources

External resources: IEC Standards | EIA-310 Rack Standards
