800mm perforated floor network cabinet – FINEN A3 Series A38827 floor standing 19-inch network cabinet with perforated metal mesh front door and bi-fold rear door.

800mm Perforated Floor Network Cabinet

Categories: , Brand:

800mm Perforated Floor Network Cabinet – A3 Series A38827 | FINEN

An 800mm perforated floor network cabinet is a combination of hardware structures designed to accommodate technical equipment including routers, switches, hubs, storage devices (UPSs), cables, and servers. Zoomtech supplies the FINEN 800mm perforated floor network cabinet (Model: A3 Series A38827) — a floor standing 19-inch cabinet delivering excellent airflow, secure locking doors, and flexible configuration for data centers, server rooms, and telecommunication facilities.

Product Overview

The 800mm perforated floor network cabinet (Model: A3 Series A38827), available through Zoomtech, is a floor standing 19-inch network cabinet manufactured by FINEN from cold-rolled steel with a wide 800mm width for extra equipment clearance. This 800mm perforated floor network cabinet features a single perforated metal mesh front door and a bi-fold perforated metal mesh rear door, ensuring superior heat dissipation and convenient access to your critical IT equipment.

Available from Zoomtech — manufactured by FINEN.

Standards & Compliance

This 800mm perforated floor network cabinet complies with the following international standards:

  • ANSI/EIA RS-310-D

  • DIN41497 Part 1

  • IEC297-2

  • DIN41494 Part 7

Front Door: Perforated Metal Mesh Door

Quick Details

Specification Details
Supplier Zoomtech
Manufacturer FINEN
Model Number A3 Series A38827
Material Cold-Rolled Steel
Protection Level IP20
Cabinet Standard IEC297-2
Type Floor Standing Network Cabinet
Height 18U / 22U / 27U / 32U / 37U / 42U / 47U
Color Serial RAL9004, RAL9005, RAL7035
Depth 600mm / 800mm / 900mm / 1000mm / 1100mm / 1200mm
Width 800mm
Front Door Single Perforated Metal Mesh Door
Rear Door Bi-fold Perforated Metal Mesh Rear Door
Mounting Profile Galvanized Zinc Coated Steel Plate – 2.0mm
Loading Capacity 800kg
Optional Accessories Cooling Fans, Shelf, PDU, Patch Panel, Switch, and Others
Packing Assembly or Dis-assembly Packing Carton
Certificate CE, RoHS
HS Code 8517709000

Product Size Chart

Model No. Capacity (U) Width (mm) Depth (mm) Height (mm) Volume (CBM)
A3.6618 18 600 600 988 0.131
A3.6818 18 600 800 988 0.152
A3.6018 18 600 1000 988 0.182
A3.8818 18 800 800 988 0.212
A3.8018 18 800 1000 988 0.24
A3.6622 22 600 600 1165 0.146
A3.6822 22 600 800 1165 0.169
A3.6022 22 600 1000 1165 0.202
A3.8822 22 800 800 1165 0.238
A3.8022 22 800 1000 1165 0.267
A3.6627 27 600 600 1388 0.166
A3.6827 27 600 800 1388 0.189
A3.6027 27 600 1000 1388 0.227
A3.8827 27 800 800 1388 0.268
A3.8027 27 800 1000 1388 0.299
A3.6632 32 600 600 1610 0.186
A3.6832 32 600 800 1610 0.211
A3.6032 32 600 1000 1610 0.252
A3.8832 32 800 800 1610 0.301
A3.8032 32 800 1000 1610 0.333
A3.6637 37 600 600 1833 0.229
A3.6837 37 600 800 1833 0.265
A3.6037 37 600 1000 1833 0.315
A3.8837 37 800 800 1833 0.364
A3.8037 37 800 1000 1833 0.405
A3.6642 42 600 600 2055 0.248
A3.6842 42 600 800 2055 0.285
A3.6042 42 600 1000 2055 0.339
A3.8842 42 800 800 2055 0.394
A3.8042 42 800 1000 2055 0.437
A3.6647 47 600 600 2277 0.291
A3.6847 47 600 800 2277 0.339
A3.6047 47 600 1000 2277 0.402
A3.8847 47 800 800 2277 0.457
A3.8047 47 800 1000 2277 0.509

Key Advantages

  1. 800mm Wide Construction – Extra clearance for high-density equipment and cable management.

  2. Perforated Mesh Front & Bi-fold Rear Doors – Excellent heat dissipation and airflow.

  3. Lockable Doors for System Security – Protect valuable hardware from unauthorized access.

  4. Two Packing Ways – Assembly or dis-assembly packing to suit your logistics needs.

  5. Multiple Depth Options – 600mm to 1200mm to fit any server room layout.

  6. CE & RoHS Certified – Meets international quality and environmental standards.

Why Buy from Zoomtech?

  • Authorized supplier of FINEN network cabinets and server racks.

  • Expert product guidance — we help you match the right cabinet to your equipment and floor space.

  • Competitive pricing on single units and bulk orders.

  • Fast response on quotes, lead times, and shipping.

  • After-sales support for configuration, accessories, and replacements.

About the Manufacturer – FINEN

FINEN is a manufacturer with 24 years’ experience, covering an area of 50,000 square meters, with more than 500 employees and a professional R&D team. Their advanced equipment — imported from Japan and Germany — includes AMADA CNC Punch Machines, TRUMPF Laser Cutting Machines, AMADA CNC Bending Machines, and CNC Automatic Spraying Lines, with a production capacity of 12,000 sets per month.

Applications

Rack cabinets for information technology and telecommunication appliances:

  • Various 19-inch servers

  • Digital Video Recorders (DVR), KVM, and routers

  • Patch panels, switches, and CCTV system equipment

  • Telephone systems and communication equipment

  • Network cabling and data center systems

  • UPS and weak current equipment

  • Other rack mount equipment

Useful Resources

External resources: IEC Standards | EIA-310 Rack Standards
